• Integrated DCC decoder, favourable price
• additional galvanic isolated 2 manual inputs (12V, 4mA)
• Dimensions and mechanical function identical with MP10
• 4 stroke levels 3.5, 6, 9.5 and 12.5 mm
• 1x independent switching contact + 1x output for powering the frog (AUX2 terminal)
• Quick setup by push button

The DP16 is equipped with a DCC interface that provides reception of digital commands and also power for the operation of the switch. DP also includes Auxiliary switch contact AUX1 for indicating and independent supply of the frog. For simplified frog supply AUX2 signal can also be used, which is connected to the DCC input wires.

For manual operation control two biDIR inputs are designed, which can control switch operation by applying input signal +- (12V/4mA). Polarity of signal determine direction or switch movement. Commands from DCC channel has higher priority over manual inputs.

Indication LED is used to signalize the status. For testing and configuration (teaching of DCC address) is used auxiliary push button.

DP16 are designed for easy installation and control of turnouts via DCC, without the need of separate accessory DCC decoder.
